Product Size
850(L) x 500(W) x 600(H)
(33⅓" x 19¾ x 23⅝")
Weight(Lb)
24.5(54)
Pipe size Φ(inch)
Φ100 (4")
Product Description
FEATURE 1
Air-intake-hole on the cover facilitates the flow and separation of running water.
FEATURE 2
Corrugated rubber packing for blocking stench is stated right below the air-intake-hole. This blocks the stench out from the cover.
FEATURE 3
All the components are easy to assemble and detach for users to clean.
FEATURE 4
It has superior ability at blocking stench, as the composed gas is emitted with filtered water through the outlet.
FEATURE 5
Drainage problem with sediment is solved by sediment blocker near the outlet.
FEATURE 6
Inlet and outlet with corrugated rubber packing prevents leaking problem and help the builder to work in simple way.
FEATURE 7
As the material is reinforced plastic(recycled car bumper), the product is strong at impact and damages. Unlike stainless products, there is no corrosion and rusts. It can be used semi-permanently.
*Superior separation ability. *
Friction between inflow wastewater and 90° elbow connected inlet surface makes vortex phenomenon with external air through the air-intake-hole. Wastewater flows down to the oil-separate-plate and FOG(fat,oil,grease) float by the plate in the middle of the product. Because of the density difference the FOG is separated from the wastewater. Then the only filtered water is emitted through the 90° elbow connected outlet. At the same time, the occurred stench inside the grease trap is emitted with the filtered water which blocks the stench. Of course, the FOG separation ability is nothing more to say.
